Chassis Specifications for the Mazda MX-5 (NC)

For the Australian Domestic Market (AUDM)

Wheel & Tyre Specs

Wheel Size

17 x 7.0 J +55 mm

Wheel Weight

7.7 kg

Bolt Pattern

5 x 114.3 mm

Tyre Size

205/45 R17

Steering

Steering Type

Rack and pinion

Steering Assist

Hydraulic power steering

Turning Radius

9.4 m

Factory Wheel Alignment

Front

Rear

Total toe-in (tyre)

1.6 mm (±4 mm)

3 mm (±4 mm)

Total toe-in (inner rim)

1.1 mm (±2.8 mm)

2.2 mm (±2.8 mm)

Total toe-in (degree)

0°09′ (±0°22′)

0°17′ (±0°22′)

Steering angle (inner)

38°42′ (±3°)

Not applicable

Steering angle (outer)

32°54′ (±3°)

Not applicable

Steering axis inclination

11°04′

Not applicable

Camber

-0°42′ (±1°)

-1°42′ (±1°)

Caster

6°32′ (±1°)

Not applicable

***Wheel alignment specifications assume stock 17 inch wheel size and tyre size 205/45R17.***

Suspension Specs

Front

Rear

Suspension Type

Double Wishbone

Multi-link (5 links)

Strut Type

Coil over spring

Spring Rate (Soft-top)

1.98 kg/mm

1.60 kg/mm

Spring Rate (PRHT)

1.98 kg/mm

1.70 kg/mm

Shock Absorber Type

Monotube

Strut Tower Brace

Yes

Brakes

Front

Rear

Brake Rotor Diameter

290 mm

280 mm

Brake Rotor Type

Ventilated disc

Solid disc

Caliper Piston Diameter

54 mm

43 mm
